DESCRIPTION

  • wide scope of skylight sizes:
    –  Type C (square): 80 x 80 cm ÷ 200 x 200 cm
    –  Type E (rectangular): 80 x 90 cm ÷ 195 x 300 cm
  • skylights are delivered as a complete product, ready to install
  • RAL palette colour selection for skylight elements
  • product certified according to PN-EN 1873
  • resistance to external fire, BROOF(t1) class according to EN 13501-5 (optional)



DESCRIPTION

  • wide scope of skylight sizes:
    –  Type C (square): 80 x 80 cm ÷ 200 x 200 cm
    –  Type E (rectangular): 80 x 90 cm ÷ 195 x 300 cm
  • skylights are delivered as a complete product, ready to install
  • RAL palette colour selection for skylight elements
  • product certified according to PN-EN 1873
  • resistance to external fire, BROOF(t1) class according to EN 13501-5 (optional)
SMOKE VENTS TYPE
Share

mcr PROLIGHT FIXED SKYLIGHTS

DESCRIPTION

  • wide scope of skylight sizes:
    –  Type C (square): 80 x 80 cm ÷ 200 x 200 cm
    –  Type E (rectangular): 80 x 90 cm ÷ 195 x 300 cm
  • skylights are delivered as a complete product, ready to install
  • RAL palette colour selection for skylight elements
  • product certified according to PN-EN 1873
  • resistance to external fire, BROOF(t1) class according to EN 13501-5 (optional)



DESIGN
Base

  • type: straight, skew, overlay
  • height: standard 30 cm - 50 cm (straight),
    15 cm - 70 cm (C/E) 30 - 70cm (NG-A) (additional option)
  • material: PVC, steel, aluminum
  • base’s thermal insulation: mineral wool of 20 mm thickness or PIR panel with 30 mm
  • possible to apply on existing plinth

Filling

  • multi-chamber polycarbonate
  • domes: acrylic or solid polycarbonate
  • multivariable single and multi-layer filling
ASK FOR AN OFFER
 Lighting



Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.

 Heat transfer


Product allows to achieve high heat transfer:

Urc ≥ 1,1 W/m²K.
 Additional elements



» safety net
» overlay base N type
» limit switch



  • Approvals
    CE
    EPD/ITM
  • Heat transfer
    Urc ≥ 1,1 W/m²K.
  • Lighting
    Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.
  • Additional elements
    » limit switch
    » overlay base N type
    » safety net

EPD_ITB_259-2021_EN

EPD_ITB_259-2021_EN

Download (2.3MB)

DTR_MCR_PROLIGHT

DTR_MCR_PROLIGHT_skylights, roof hatchways_v 1.0.3 eng

Download (1.17MB)

2023_FOLDER_PROLIGHT

2023_FOLDER_PROLIGHT - smoke exhaust vents, skylights, roof access hatches_EN

Download (887.32KB)

2022_Technical_Catalogue

2022_Technical_Catalogue_PROLIGHT_EN_WWW

Download (4.76MB)
