mcr PROSMOKE FIXED SMOKE CURTAINS

$0.00

Tax excluded

DESCRIPTION

fixed S type smoke curtains are responsible for separation
of smoke zones under the ceiling of the building
they are mainly used in large-area buildings, such as warehouses, production and sports halls or malls, where the use of light curtains of large size and guaranteed resistance to high temperature is necessary
fire resistance parameters: D180/DH60 (fabric)
smoke-tight fabric made of glass fibre double-coated with polyurethane
bottom balast made of steel elements of maximum length 3 m
painting steel components with chosen RAL palette colour
Certificate of constancy of performance CE 1396-CPR-0022 as per EN 12101-1

DESCRIPTION

fixed S type smoke curtains are responsible for separation
of smoke zones under the ceiling of the building
they are mainly used in large-area buildings, such as warehouses, production and sports halls or malls, where the use of light curtains of large size and guaranteed resistance to high temperature is necessary
fire resistance parameters: D180/DH60 (fabric)
smoke-tight fabric made of glass fibre double-coated with polyurethane
bottom balast made of steel elements of maximum length 3 m
painting steel components with chosen RAL palette colour
Certificate of constancy of performance CE 1396-CPR-0022 as per EN 12101-1

DESIGN
Base

Fixed control fabric curtain - structure

Approvals

CE
CPR
Non-standard options

installation passages in fixed curtains
» elements painted to any RAL colour
» guides
» service passage
Separation of smoke zones

Separated smoke zones stop the spread of smoke in passageways, staircases, stairs and hold the smoke in a room adjacent to the evacuation route. Correct arrangement of smoke curtains in the facility allows the smoke to be directed towards other
