Tornatech is a Canada-based manufacturer and a global leader in fire pump controllers.

Tornatech is a Canada-based manufacturer and a global leader in fire pump controllers. Its products fully comply with NFPA 20 standards—the strictest regulations in fire safety—and hold UL (Underwriters Laboratories) listing and FM (Factory Mutual) approval.

Tornatech controllers feature advanced ViZiTouch touchscreen interfaces that make monitoring, testing, and managing system data exceptionally easy.

The company's product range is primarily divided into the following categories:

1. Electric Motor Fire Pump Controllers (GPx Series)

Designed to control and operate electric fire pumps.

• Featured Models: GPx-FM Series and standard GPx Series.

• Specifications: Offers a voltage range of 200V to 600V and a capacity range of 5 to 500 Horsepower (HP). Overcurrent protection, phase reversal indication, and an emergency start handle come as standard. An Automatic Transfer Switch (ATS) for generator switching can be integrated optionally.

• VFD Alternative (VPx Series): Variable Frequency Drive (VFD) models optimize motor speed within 10 seconds to maintain constant system pressure.

2. Diesel Engine Fire Pump Controllers (Model GPD)

Manages diesel-driven backup or primary fire pumps to ensure operation in the event of an electrical power failure.

• Featured Model: Model GPD. • Features: Includes both manual and automatic operating modes. The panel houses two independent automatic battery chargers (supporting 12V or 24V DC). Features include a weekly automatic test run timer, a pressure recorder, and engine fault alarms.

3. Jockey Pump Controllers

Controls small auxiliary pumps used to compensate for pressure drops caused by minor leaks in the fire protection system and to prevent the main fire pump from operating unnecessarily.

• Models: Available in single, dual, or variable speed drive (VSD) configurations—such as JPLT, JPY, and JPD—to suit various requirements.

4. Specialized and High-Voltage Solutions

• Model GPL (Limited Service): A more economical electric control panel option for projects with motor ratings up to 30 HP that do not require FM approval.

• Model MPA (Medium Voltage): Designed to safely control electric motors (100–4500 HP) operating at high voltages ranging from 2200V to 6900V in large industrial facilities. Technical Summary Table

Feature Electric (GPx) Diesel (GPD) Jockey Pump (JPx)

Certifications UL, FM, NFPA 20 UL, FM, NFPA 20 UL 508A, CE

Standard Enclosure NEMA 2 (Optional IP66) NEMA 2 (Optional IP66) NEMA 2 / IP55

User Interface ViZiTouch 2.1 Color Display ViZiTouch 2.1 Color Display ViZiLT or iPD+

Power Supply 200V - 600V AC 120V - 240V AC (For Battery Charging) Single-phase or Three-phase
