HDPE Butt Fusion End Cap

$0.00
Tax excluded

HDPE Butt Fusion End Cap

Raw Materials: PE100, PE100RC
Standards : EN12201, ISO 4427, AS/NZS 4129
Diameter: DN63-800mm (Larger size can be customized)
PressureRating: SDR9, SDR11, SDR13.6, SDR17
Certificates: UL, WRAS, NSF, ISO, CE
Color: Black, colors can be customized
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Product Specification

HDPE Butt Fusion Stub End03

dn L H D1 D e e e
SIZE(dn) mm　 mm　 mm　 mm　 SDR17 SDR13.6 SDR11
F50 73 64 55 80 　 　 4.6
F63 82 70 68 96 　 　 5.8
F75 86 74 80 110 　 　 6.8
F90 103 84 95 128 　 　 8.2
F110 123 103 116 150 　 　 10
F125 113 93 130 158   9.2 11.4
F140 110 90 145 182 　 10.3 12.7
F160 127 105 165 203 　 11.8 14.6
F180 135 110 190 212 　 13.3 16.4
F200 143 120 205 252 　 14.7 18.2
F225 135 112 230 268 　 16.6　 20.5
F250 168 136 260 320 　 18.4 22.7
F280 160 133 285 318 　 20.6 25.4
F315 168 135 335 370 　 23.2 28.6
F355 155 125 360 430 　 26.1 32.2
F400 172 135 415 482 23.7 29.4 36.3
F450 188 142 465 530 26.7 33.1 40.9
F500 218 168 515 585 29.7 36.8 45.4
F560 220 172 570 625 33.2 41.2　 50.8
F630 230 175 645 685 37.4 46.3 57.2
F710 230 170 730 800 42.1 52.2 　
F800 230 170 820 905 47.4 58.8 　
F900 230 170 920 1000 53.3 　 　
F1000 260 200 1020 1100 59.3 　 　
F1200 300 225 1220 1300 71.1
F1400 400 295 1430 1500 83.0

Product Description

HDPE Butt Fusion End Cap is a terminal sealing component designed for HDPE pipe systems. It uses hot-melt butt technology to achieve seamless connection with the pipe to ensure the integrity and sealing of the system. This product is widely used in municipal engineering, chemical pipelines, water supply and drainage systems and other fields, and is an indispensable key component in pipeline construction.



Core features of HDPE Butt Fusion End Cap

1. High-quality materials: Made of PE100/PERC grade high-density polyethylene (HDPE), it has excellent chemical corrosion resistance and can resist corrosion from most acid, alkali and salt solutions, making it particularly suitable for chemical industry applications.

2. Reliable connection: Designed specifically for Butt Fusion process, it forms a molecular-level bond through hot-melt welding, and the interface strength is higher than the pipe body, ensuring the same strength and sealing performance as the pipe.

3. Diversified specifications: The size ranges from DN63mm to DN800mm, and the color can be customized according to customer requirements to meet different engineering needs.

4. Long life design: With HDPE pipe system, the service life can reach more than 50 years, with excellent resistance to environmental stress cracking, suitable for underground burial or harsh environment applications.



Main application areas

Municipal engineering: terminal sealing of urban water supply and drainage systems, rainwater collection systems and sewage treatment pipe networks

Chemical industry: terminal protection of chemical industry water supply pipe systems, strong corrosion resistance

Construction engineering: end closure of building rainwater pipes, underground drainage pipes, and sewage pipes

Agricultural irrigation: pipe terminal sealing of farmland irrigation systems



Product advantages

Easy installation: HDPE Butt Fusion Welding Machines can achieve fast and reliable connections and improve construction efficiency

Environmental protection and safety: the material is non-toxic, meets food-grade contact standards, and can be used in drinking water systems

Economical and practical: lighter than metal end caps, with low transportation and installation costs and simple maintenance

Strong adaptability: working temperature range -60℃ to 60℃, excellent cold resistance
