mcr S-THERM SMOKE VENTS

Name: mcr S-THERM SMOKE VENTS
Brand: Mercor
SKU: 328
Availability: BackOrder

Mercor

$0.00

Tax excluded

mcr S-THERM SMOKE VENTS

DESCRIPTION

no thermal bridges, reduction of water vapour condensation
high aesthetics, use of extruded aluminum profiles, wooden base option
modular design enables work ergonomics during assembly and transport
wide scope of vents sizes:
– Type C (square): 100 x 100 cm ÷ 180 x 180 cm
– Type E (rectangular): 150 x 250 cm ÷ 180 x 250 cm
– Type NG-A (skew base): 110 x 110 ÷ 190 x 260 cm
optional wind - and/or inlet deflector for better aerodynamic performance
simple replacement of vent elements - filling, thickness, type and colour change
RAL palette colour selection for vent elements
product certified according to PN EN 12101-2, CE marked

mcr S-THERM SMOKE VENTS

DESCRIPTION

no thermal bridges, reduction of water vapour condensation
high aesthetics, use of extruded aluminum profiles, wooden base option
modular design enables work ergonomics during assembly and transport
wide scope of vents sizes:
– Type C (square): 100 x 100 cm ÷ 180 x 180 cm
– Type E (rectangular): 150 x 250 cm ÷ 180 x 250 cm
– Type NG-A (skew base): 110 x 110 ÷ 190 x 260 cm
optional wind - and/or inlet deflector for better aerodynamic performance
simple replacement of vent elements - filling, thickness, type and colour change
RAL palette colour selection for vent elements
product certified according to PN EN 12101-2, CE marked

DESIGN
Base

type: straight, skew
height: 20 cm - 70 cm
material: steel
prepared for insulation of 50 mm thickness
delivered in assembly components
possible to apply on existing plinth

Filling

multi-chamber polycarbonate
domes: acrylic or solid polycarbonate
ALU sandwich panel
multivariable single and multi-layer filling

Control system

smoke exhaust: electric (24 V-), pneumatic
ventilation: electric (230 V~), pneumatic

ASK FOR AN OFFER

Smoke exhaust

Exhaust smoke, combustion gases and heat energy from enclosed spaces (production floors, storage spaces, public facilities, etc.) to the outside of builings, in order to protect human lives and property.

Lighting

Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.

Ventilation

Provides air supply and daily ventilation.

Additional elements

» wind deflectors (C, E)
» inlet deflectors
» safety net
» limit switch

Heat transfer

Product allows to achieve high heat transfer:

Urc ≥ 0,9 W/m²K.

Application

Wide scope of shapes and sizes enable
installation on warehouses, public
services buildings, shopping malls,
commercial and sport objects.

Brand

Approvals

CE
CPR
Heat transfer

Urc ≥ 0,9 W/m²K.
Ventilation

Provides air supply and daily ventilation.
Lighting

Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.
Smoke exhaust

Exhaust smoke, combustion gases and heat energy from enclosed spaces (production floors, storage spaces, public facilities, etc.) to the outside of builings, in order to protect human lives and property.
Additional elements

» limit switch
» safety net
» wind deflectors
