TFDF IR Single infrared flame detector.

Single infrared flame detector tuned on flame pulses and immune to false alarms. Suitable to detect flames generated by fuels, gases, paints, alcohol, paper, wood, etc.. Manual and automatic test function. Vision cone 90 degrees. VdC power supply. Maximum absorption 50 mA. Operating Temperature -20 , +60. 95% relative humidity non-condensing, protection class IP66. Dimensions 180x85x65, weight 700gr. Approved: VDS EN54-10. Class 1. Certificate of homologation 0786-CPD 21103
